EF 100-400mm f/4.5-5.6L IS II USM
- Compact, high-performance L-series super-telephoto zoom makes it ideal for sports and wildlife photography
- Rotation-type zoom ring allows for more precise composition and balance when handholding
- Optical Image Stabilizer provides up to four shutter speed steps of correction
- New Air Sphere Coating (ASC) helps to significantly reduce backlit flaring and ghosting
-
OVERVIEW
-
SPECIFICATIONS
-
ACCESSORIES
-
RESOURCES
-
SUPPORT
-
MISCELLANEOUS
The EF 100-400mm f/4.5-5.6L IS II USM lens delivers a superb combination of cutting-edge performance, compact construction and brilliant resolving power that’s great for sports and wildlife photography. The lens features one fluorite and one super UD element to help provide impressive contrast and resolution with reduced chromatic aberration across the entire zoom range. Canon’s new Air Sphere Coating (ASC) helps significantly reduce backlit flaring and ghosting, while fluorine coatings on the front and rear lens surfaces help lessen smears and fingerprints. A 9-blade circular aperture renders beautiful, soft backgrounds, and a 3 mode (standard, panning and exposure only) Optical Image Stabilizer provides up to 4 steps* of image correction. The new inner focusing AF system helps ensure fast and accurate focus down to 3.2 ft. with a .31x maximum magnification. Usability enhancements include a rotation-type zoom ring with adjustable zoom torque for more precise, customizable zoom performance, a redesigned tripod mount that can be attached and detached without removing the lens from the camera, and an all-new lens hood with a side window that makes it simple to adjust specialty filters-like polarizers-without the need to remove the hood. Ruggedly constructed with advanced dust and water sealing for durability in a range of environments, the EF 100-400mm f/4.5-5.6L IS II USM lens is a stellar performer with refined controls for a wide variety of situations.
Sample Image
MTF Chart

















Compact, high performance L-series super-telephoto zoom makes it ideal for sports and wildlife photography.
One fluorite and one super UD lens element provides excellent correction of chromatic aberration throughout the entire zoom range, helping to deliver high-quality images with high resolution and contrast.
Rotation-type zoom ring allows for more precise composition and excellent balance when handholding.
Inner focusing, ring USM, a high-speed CPU and optimized AF algorithms for fast and accurate autofocusing.
Optical Image Stabilizer provides up to four shutter speed steps of correction*.
Three image stabilization modes (standard, panning, and during exposure only) provide outstanding results for a wide range of shooting situations.
Improved zoom torque adjustment ring allows easy setting of zoom tension.
New Air Sphere Coating (ASC) helps to significantly reduce backlit flaring and ghosting.
Highly resistant to dust and water, and amazing durability enabling shooting even in harsh conditions.
Circular aperture (9 blades) helps deliver beautiful, soft backgrounds.
Fluorine coating on front and rear lens surfaces helps reduce smears and fingerprints.
Lens hood with side window permits specialty filters to be adjusted with hood in place.
Newly designed tripod mount can be attached or detached without removing the lens from the camera.
Minimum focusing distance of 3.2 ft. / 0.98 m with 0.31x maximum magnification.
(400mm focal length, when using the EOS-1D X).
Focal Length Maximum Aperture | 100-400mm 1:4.5-5.6 |
Lens Construction | 21 Elements In 16 Groups |
Diagonal Angle Of View | 24°-6°10' |
Focus Adjustment | Inner Focus System / USM |
Closest Focusing Distance | 3.2 Ft. / 0.98m |
Zoom System | Rotation Type |
Filter Size | 77mm |
Max Diameter X Length Weight | Approx. 3.7" X 7.6"/94 X 193mm Approx. 3.46 Lbs./1570g (Without Tripod Mount) Approx. 3.62 Lbs./1640g (With Tripod Mount) |

Extension Tube EF-12 II
Extension Tube EF 12 II is especially suited for close-focusing with wide-angle lenses.

77mm Close-Up Lens 500D
Canon Close-Up Lens 500D is a double-element accessory that attaches to front of lens. It changes closest focusing distance from infinity to 500mm (approx. 19.7" from front of lens).

Extender EF 2x III
Designed to extend a lenses focal length by a factor of 2x, the Canon Extender EF 2X III delivers optical performance on par with the finest Canon super telephoto lenses. It delivers seamless communication among camera body, lens and extender, and features coatings to minimize ghosting, flare and chromatic aberration. The Fluorine coating resists soiling, smears and fingerprints. Extender EF 2X III meets all necessary standards in terms of rugged, dustproof and water-resistant construction, and should be in every professional's camera bag.

Extension Tube EF-25 II
25mm fully coupled Extension Tube for EOS camera and most lenses to 350mm.

Extender EF 1.4x III
Extending a lenses focal length by a factor of 1.4x, Extender EF 1.4X III incorporates phenomenal optical performance with minimal chromatic aberration and is a perfect complement to many of Canon super telephoto lenses. The Fluorine coating resists soiling, smears and fingerprints. Extender EF 1.4X III maintains high standards not only optically, but also in terms of rugged, dustproof and water resistant construction.

Rain Cover ERC-E5S
Protects camera and lens when shooting during inclement weather conditions. A large transparent window allows viewing of the LCD monitor. Includes Eyecup L and Eyecup S to fit all EOS cameras.

Lens Case LZ1326
Lens zipper-type soft cases are compact, yet keep your lenses looking like new.

Lens Hood ET-83D
Designed to prevent stray light from entering the lens in order to keep unwanted glare from affecting your photographs. A circular polarizing filter operation window is located on the hood, allowing operation of a circular polarizing filter.

Lens Dust Cap E Rear Cap
Rear lens cap for all EF type lenses, lens extenders, and extension tubes. Used to protect the rear glass element from dust and scratches.

Lens Cap E-77 II
The Lens Cap E-77 II is newly designed and fits Canon EF lenses with a 77mm filter size. It helps protect the front glass from dust and scratches.

Gelatin Filter Holder Adapter III
The Gelatin Filter Holder Adapter III allows the use of commercially available square filters without the need for cutting. The holder attaches to the lens through an adapter that fits the filter diameter. Use with 3-inch square type III gelatin filters. Gelatin filters can be used with most EF lenses.

Gelatin Filter Holder Adapter IV 77
The 77mm Gelatin Filter Holder Adapter IV 77 is used to attach the Gelatin Filter Holder IV to most EF lenses.

77mm Filter UV Protector
These filters can help protect your lens against dust, moisture, fingerprints, scratches and damage and can be kept on your lens at all times. Filter fits select lenses with a 77mm diameter.

77mm Circular Polarizer PL-CB
Filter enhances picture quality by blocking harmful reflected light.
